This is a true profile image illustrating the extreme
pointing capabilities attainable due to the short knee wall height.
The telescope is limited by trees not the knee walls or southern
end wall (not drawn yet). |
|
|
|
|
Telescope shown pointing to zenith. |
|
|
|
|
Telescope angled toward arch at a 45 degree
angle. Appears to be obstructed by the arch top when pointing
north. Possibly 50 degrees is the lowest pointing capability
when pointing due north. |
|
|
